Food and beverage
Juice, soy milk, plant-protein drinks and flavored milk
Image coming soon
Image coming soon
Colloid Mills
JMS-50 Laboratory Colloid MillCompact Wet Grinding & Emulsifying Machine
Interested in this product?
Share your material, required capacity and target result for a model recommendation and quote.
The selected product is added to the inquiry automatically.
Email: info@herenex.com
WhatsApp: +86 134 8238 0109
Typical applications
Use the material itself to understand the application range. Final configuration still depends on material testing and technical confirmation.
Fruit, vegetable and spice
Vegetable pulp, spice paste, fruit and vegetable pulp, and meat paste
Viscous sauces
Peanut butter, sesame paste, tomato sauce and emulsified sauces
Pharma and personal care
Creams, wash-care products, suspensions and homogenized emulsions
Chemicals and materials
Pigments, resin emulsions, adhesives and chemical pastes
Material selection reference
First assess viscosity, solids content, fibers and particles, then combine the target fineness and required throughput. Where categories overlap, use the main processing difficulty or the more conservative category.
01
Beverage - low-viscosity homogenizing
- Material
- Soy milk, plant-protein drinks and juice bases
- Selection basis
- Continuous low-viscosity feeding; focus on suspension and target fineness
02
Beverage - suspension stabilizing
- Material
- Pulp drinks, milkshakes and drinks with stabilizers
- Selection basis
- Premix thoroughly; test the formulation as viscosity rises
03
Starch / grain - pumpable slurry
- Material
- Rice slurry, corn slurry, starch slurry and grain slurry
- Selection basis
- Ungelled and pumpable; diamond or compound teeth
04
Starch - gelatinized high viscosity
- Material
- Cooked rice paste, gelatinized starch slurry and gel slurry
- Selection basis
- Test at the highest viscosity, temperature and solids content
05
Fibrous slurry / meat paste
- Material
- Vegetable pulp, spice paste, meat paste and soft-bone slurry
- Selection basis
- Pre-crush and keep continuously pumpable; inclined teeth preferred
06
Oil-based sauces
- Material
- Peanut butter, sesame paste, nut butter and oil chili
- Selection basis
- Focus on solids, temperature rise and fineness; compound teeth preferred
07
Personal care / pharma - pastes and suspensions
- Material
- Toothpaste, creams, ointments and oral suspensions
- Selection basis
- Confirm cleaning and contact-material requirements separately
08
Industrial slurry / chemical media
- Material
- Pigment slurry, resin emulsion, asphalt emulsion and adhesives
- Selection basis
- Select separately for corrosion, abrasion, explosion protection and temperature control
JMS-50 food-material capacity and verification
The current JMS-50 reference value is 5–30 kg/h for category 01 low-viscosity homogenizing. Other listed food categories require a material trial.
Categories 07 and 08 must be calculated separately from the material condition and confirmed equipment configuration.
| Material category | JMS-50kg/h |
|---|---|
01Beverage - low-viscosity homogenizing | 5-30 |
03Starch / grain slurry | Trial required |
05Fibrous slurry / meat paste | Trial required |
06Oil-based sauces | Trial required |
02
Suspension-stabilized beverages
With a low additive level and thorough premixing, category 01 may be used as a reference. Test the formulation when viscosity rises.
04
Gelatinized high-viscosity slurry
Calculate from the highest processing viscosity, temperature and solids content; do not apply a fixed conversion ratio.
JMS-50 for small-batch process evaluation
The JMS-50 is the compact model in the current JMS range. It is intended for small-volume wet grinding, emulsifying, homogenizing and refining where the material, target texture and operating conditions can be checked before the final configuration is fixed.
JMS-50 reference specifications
| Model | Motor power | Speed | Reference fineness | Comprehensive capacity range | Reference weight |
|---|---|---|---|---|---|
| JMS-50 | 1.5 kW | 3,000 r/min | 2–150 μm | 0.005–0.03 t/h | 68 kg |
Reference values, not a performance guarantee. Actual throughput and fineness vary with viscosity, solids content, feed size, fibers or soft particles, working gap, temperature, feeding method and the number of passes. Conflicting dimension records are not displayed until the measurement scope is confirmed.
What this model is designed to do
- Wet grinding and refining: process pumpable slurries, emulsions and pastes in small batches.
- Shearing, emulsifying and homogenizing: use the stator-rotor working zone to evaluate texture and process response.
- Process screening: compare material behavior, target fineness, temperature rise and recirculation needs before confirming the final setup.
Information needed before confirming the configuration
- Material name, viscosity, solids content, feed size, fibers and soft particles
- Required batch size or hourly output, daily running time and feeding method
- Target fineness or texture, acceptable temperature rise and expected passes
- Voltage, frequency, phase, cleaning requirements, contact-material needs and installation limits
For high-viscosity, high-solids, fibrous, abrasive, corrosive or critical applications, a material test and technical confirmation are required before the configuration is fixed.
Request a Quote for This Product
Share your material, required capacity and target result for a model recommendation and quote.
Selected product: JMS-50 Laboratory Colloid Mill | Compact Wet Grinding & Emulsifying Machine
Information that helps us quote accurately
Material or productRequired capacityTarget resultVoltage and frequency
